Bixolon XM7 Series mobile printer
XM7-20: A compact 2-inch (58mm) printer ideal for printing labels in limited spaces. With fast printing and robust design, it is ideal for logistics, retail and warehousing.
XM7-30: 3-inch (80mm) mobile printer that combines speed and reliability. Equipped with advanced connectivity features, it allows easy integration with various systems, making it suitable for a wide range of industrial applications.
XM7-40: The largest printer in the series, the 4-inch (112mm) printer offers advanced features such as built-in peeler, adjustable paper guide and USB Type-C® charging support. With its rugged design and high-speed printing, it's ideal for intensive tasks in harsh environments.
All models in the XM7 series feature rugged construction, resistance to drops from heights of up to 2.1 meters and an IP54 rating for protection against dust and water. In addition, they support a variety of connectivity options, including Bluetooth® and Wi-Fi, enabling seamless integration with existing systems. The XM7 series is a reliable solution for professionals looking for durable and efficient mobile printers for industrial applications.
Print Type
- Method: Direct Thermal
- Resolution:203 dpi
- Maximum print speed:
- XM7-20: 152 mm/s
- XM7-30: 127 mm/s
- XM7-40: 127 mm/s
Media type:
- Type: Labels, linerless labels (optional), receipts
- Maximum print width:
- XM7-20: 48 mm
- XM7-30: 72 mm
- XM7-40: 104 mm
- Media width:
- XM7-20: 25-58 mm
- XM7-30: 25-80 mm
- XM7-40: 50-112 mm
- Media thickness: 0.07-0.19 mm
- Maximum roll diameter:
- XM7-20: 57 mm
- XM7-30, XM7-40: 66 mm
Functions and accessories:
- Display: TFT LCD (IPS, 240 x 320 px)
- Support for 1D and 2D barcodes
- Sensing: end of paper, black marker, lid opening, peel off labels (peeler optional)
- Easy paper loading
Memory:
- 128 MB SDRAM, 256 MB Flash (standard)
- Optional: 256 MB SDRAM, 512 MB Flash
Battery:
- Type: Li-ion, Smart Battery, rechargeable
- Capacity:
- XM7-20: 2850 mAh
- XM7-30: 3400 mAh
- XM7-40: 6800 mAh
- Power Delivery USB-C charging support
Communication interfaces:
- Standard: USB V2.0 HS, RS-232
- Optional: Bluetooth, WLAN (802.11a/b/g/n, WEP40/104, WPA1/2), NFC
- Emulations: SLCS, BPL-Z™, BPL-C™
Operating and protection conditions:
- Operating temperature: -15°C to 50°C
- Storage temperature: -30°C to 70°C
- Operating humidity: 10-80% RH
- Fall resistance:
- XM7-20, XM7-30: 2.1 m
- XM7-40: 1.8 m
- Resistance rating: IP54
Dimensions and weight:
- XM7-20: 93 x 168 x 69 mm, 600 g (with battery)
- XM7-30: 119 x 180 x 79 mm, 795 g (with battery)
- XM7-40: 158 x 186 x 82 mm, 1,090 g (with battery)
Additional accessories (optional):
- Belts (shoulder, belt)
- Chargers (single, four-station)
- Car adapters
- Vehicle mounts
- Docking stations (for XM7-20)
Applications and software:
- Systems supported: Android, iOS, Windows, Linux
- SDK: Android/iOS/Windows/Linux/Chrome/Xamarin/Web Print
- Device management support: XPM™, XCM™, SOTI Connect
Rainbow Tours resorts are using Bixolon equipment in Greece, Mexico and the Dominican Republic, among others.
