RuggON PX501 industrial tablet
Equipped with a 10.1-inch Full HD screen with optical enhancement technology, it provides excellent visibility even in harsh sunlight. The rugged case meets IP65 and MIL-STD-810G standards to ensure resistance to water, dust, vibration and drops from up to 1.5 meters. The tablet offers impressive performance thanks to a state-of-the-art Intel® Core™ processor and support for the Windows 10 operating system. The RuggON PX501 provides extensive connectivity, including Wi-Fi, LTE, GPS and Bluetooth, for efficient work in the field. Optional modules, such as a barcode reader, RFID and an additional USB port, enhance the device's functionality. With a replaceable battery with a long battery life, the RuggON PX501 is ideal for industries such as logistics, industry, transportation and emergency services, offering reliability and performance in all conditions.
Processor
- Intel® Core™ i5-1335UE
- Intel® Core™ i7-1365UE
- Intel® Processor U300E
RAM
- 8 GB DDR5 SDRAM
- optional 16 GB/32 GB DDR5 SDRAM
Drive
- 128 GB PCIe M.2 SSD,
- optional 256 GB/512 GB/1 TB PCIe M.2 SSD
Operating system: Windows 11 GAC support
Durability
- Certifications: IP65, MIL-STD-810H, MIL-STD-461G
- Resistance to vibration, shock and drops from 1.5 meters
Operating temperature range: from -20°C to +60°C
Display
- 10.1" TFT LCD WUXGA (1920 x 1200), Gorilla Glass
- 1000 nits brightness, sunlight readable, dimming option
Multi-point touchscreen:
- glove operation
- water resistance
- 2mm hard tip stylus support
- Optional: digital stylus with IP54 certification
Interface I/O
- USB 3.1 Type A x 1, Thunderbolt™ 4 Type C x 1
- RS-232 x 1, optional USB 2.0 or Micro SD slot
- Gigabit Ethernet (RJ45) x 1
- Audio connector for headset x 1
- Nano SIM slot x 2
- Optional: RF connector for WLAN/GNSS/WWAN x 2
- Docking connector x 1
- Power connector (DC-in) x 1
Extension options
- Built-in 2D barcode reader (optional OCR)
- NFC module + Smart Card reader 2-in-1
- Fingerprint reader, MRZ reader
- Snap-on connector for customization
Communication
- Wi-Fi 6E (802.11ax)
- Bluetooth V5.3
- GNSS (GPS/GLONASS/BeiDou)
- Optional: 4G LTE/5G (Sub-6G), Iridium LEO satellite
Camera
- Front camera: 2 MP
- Rear camera: 8 MP with autofocus and LED flash
- Rear camera
Power supply
- AC power adapter (65 W, 100-240 V AC, 50/60 Hz)
- Li-ion 4500 mAh battery with hot-swappable, optional 9000 mAh
- Fast charging support
